Grout mixing and pumping unit combines a mixer, agitator, and hose type grouting pump. And the function switch between mixer and agitator is realized by using squeeze switch. LGP800/1200/130H-E is a grout mixing and pumping unit that combines a mixer, agitator, and hose type grouting pump. And the function switch between mixer and agitator is realized by using squeeze switch.
High speed vortex mixer of LGP800/1200/130H-E high strength grout unit ensures mix quickly and evenly. Water, cement and other media are quickly mixed into a homogeneous slurry. Then the mixed slurry is delivered to the grout agitator. Grout hose pump injects from the mixing drum (storage tank). This ensures a continuous mixing and grouting operations.

Technical data of high strength grout unit:
The mixer volume of LGP800/1200/130H-E high strength grout unit is 800L, its agitator volume is 1200L. The working pressure of its hose pump is 1.5Mpa, the rated output is 8m3/h and hose pump output is 30-130L/min.

Application of high strength grout unit:
LGP800/1200/ 130H-E high strength grout unit is suitable for mixing and pumping water, cement, bentonite, clay powder, silicates and other additives. And it is mainly used for highways, railways, water and electricity, construction, mining etc. ground and underground construction project.

Features of high strength grout unit:
1. It have a compact size. This machine is combination of grout mixer, agitator and squeeze hose pump and power in one base frame;
2. Flow is adjustable;
3. Its pump is squeeze hose pump. The hose is the only spare part, it is easy to operate and maintenance;
4. Butterfly connection mixer and agitator, flexible switching;
5. Imported electrical components, it is safe and reliable;
6. High-power and high-speed eddy current pulping, it is fast and evenly.

Maintenance of high strength grout mixing and pumping unit:
In order to ensure the normal operation of the grout mixing and pumping unit during use, reduce the failure rate, improve work efficiency, and reduce maintenance costs. When using the grout mixing and pumping unit, it should be maintained regularly, carefully maintained, and scientifically maintained to increase the life of the grout unit.
1. After use, clean up the grouting pump pipeline to prevent residual cement slurry from solidifying and causing blockage;
2. Brush lubricating oil on the lubricated parts to prevent rust; replace the lubricating oil in the box after long-term use, and do a good job of preventing rust and moisture;
3. Regularly check the key components of the colloidal grout plant, and tighten the screws if they are loose.

Contact us for grout mixing and pumping unit price:
We are high strength grout mixing and pumping unit supplier and manufacturer for many years. We have rich experience and technology. We could also customize grout unit according to your project demands.
We have many standard models for your option. Please tell us your requirements and we will provide you with the corresponding product parameters and quotations:

1. What rated flow and working pressure grout unit do you need?
2. How about the water and cement ratio, does any sand in?
3. Regarding the engine, do you want an electric engine or a diesel engine? If you need an electric engine, please let us know your local voltage.
You can send your demands to our email, email address: sales@leadcrete.com.
