LRM 100kg 250kg 500kg Refractory Castable Pan Mixer
LRM refractory castable mixers are designed by refractory castable mixer manufacturer Lead Equipment for mixing refractory materials, castable materials, etc.
LRM100
100kg
33rpm
4kw
1100mm
1.4*1.3*1.1m
PRODUCTS LIST
HOT products
Inquiry
Introduction
Product Details
Technical data
Cases
Inquiry
Description
LRM refractory castable mixers are designed by refractory castable mixer manufacturer Lead Equipment for mixing refractory materials, castable materials, etc.
LRM refractory castable mixer can be used in both stationary and mobile designs. It features outstanding performance. To ensure easy movement in the workplace, the LRM100 and LRM250 refractory pot mixers are equipped with walking wheels, and the LRM500 frame has forklift holes. The bottom and inner walls of the mixer have a highly wear-resistant steel lining, and five pieces of mixing arms for different purposes can evenly mix the refractories without voids.
LRM refractory castable mixer can be used in both stationary and mobile designs. It features outstanding performance. To ensure easy movement in the workplace, the LRM100 and LRM250 refractory pot mixers are equipped with walking wheels, and the LRM500 frame has forklift holes. The bottom and inner walls of the mixer have a highly wear-resistant steel lining, and five pieces of mixing arms for different purposes can evenly mix the refractories without voids.
Application
Compared with ordinary concrete mixers, LRM refractory castable mixers have many outstanding features. The mixing speed and homogeneity are very high. With internal lining to prevent the abrasion of the mixed material on the drum, the replaceable high wear-resistant lining can be continued, low maintenance cost and long service life
LRM refractory castable mixers are used to mix refractories, castables, friction materials, chemical materials, precast concrete, mortar, aggregate mixes and glass materials. Can be used in conjunction with refractory wet shotcrete machine for spraying refractory materials in steel industry.
LRM refractory castable mixers are used to mix refractories, castables, friction materials, chemical materials, precast concrete, mortar, aggregate mixes and glass materials. Can be used in conjunction with refractory wet shotcrete machine for spraying refractory materials in steel industry.
Features
LRM refractory castable mixers are the best-selling products of refractory castable mixer manufacturer Lead Equipment, which are exported to home and abroad.
The specific characteristics of the 100kg 250kg 500kg refractory pan mixer are as follows:
1. Pan mixer;
2. Special designed for site operation;
3. Fast mixing speed and homogenous;
4. Compact structure;
5. Comfortable feeding height;
6. Easy to move;
7. With bag breaker;
8. Water spray nozzles;
9. Low maintenance cost.
Safety Feature:
If the top lid door is opened in between the operation, machine can stop automatically. Because there is a limit switch between the top lid door and the hopper, once the top lid is opened, the power will cut off automatically and confirm the safety for operator.
The specific characteristics of the 100kg 250kg 500kg refractory pan mixer are as follows:
1. Pan mixer;
2. Special designed for site operation;
3. Fast mixing speed and homogenous;
4. Compact structure;
5. Comfortable feeding height;
6. Easy to move;
7. With bag breaker;
8. Water spray nozzles;
9. Low maintenance cost.
Safety Feature:
If the top lid door is opened in between the operation, machine can stop automatically. Because there is a limit switch between the top lid door and the hopper, once the top lid is opened, the power will cut off automatically and confirm the safety for operator.
Product Details
-
.jpg)
Electric control box for refractory pan mixer -
Mixing blade and wear-resistant linner -
.jpg)
Limit switch for protection operator -
Refractory pan mixer equipped with ABB variable-frequency drive -
Refractory pan mixer with hydraulic discharge door -
Planetary mixing
Technical Parameters
Technical Data
| Item | LRM100 100kg Refractory Castable Mixer | LRM250 250kg Refractory Castable Mixer | LRM500 500kg Refractory Castable Mixer |
| Mixing capacity | 100kg | 250kg | 500kg |
| Rotating speed | 33rpm | 34rpm | 36rpm |
| Motor Power | 4kw | 7.5kw | 11kw |
| Feeding Height | 1100mm | 1200mm | 1300mm |
| Dimensions | 1.4*1.3*1.1m | 1.48*1.38*1.23m | 1.7*1.25*1.35m |
| Weight | 550kg | 650kg | 1010kg |
| Note：Technical data may change due to technical progress，subject to modification without notice. | |||
.jpg)
